The Source/Drain Engineering of Nanoscale Germanium-Based MOS Devices

The Source/Drain Engineering of Nanoscale Germanium-Based MOS Devices Synopsis

This book mainly focuses on reducing the high parasitic resistance in the source/drain of germanium nMOSFET. With  adopting of the Implantation After Germanide (IAG) technique, P and Sb co-implantation technique and Multiple Implantation and Multiple Annealing (MIMA) technique, the electron Schottky barrier height of NiGe/Ge contact is modulated to 0.1eV, the thermal stability of NiGe is improved to 600? and the contact resistivity of metal/n-Ge contact is drastically reduced to 3.8P10?7?cm2, respectively. Besides, a reduced  source/drain parasitic resistance is demonstrated in the  fabricated Ge nMOSFET. Readers will find useful information about the source/drain engineering technique for high-performance CMOS devices at future technology node.
